E3D v6 mount with Inductive Sensor
par o0aaron0o
Fichiers imprimables (5)
-
stl12mm_-_E3Dv6_InductionMount.STL
238 Ko · 1 303 téléchargements
-
stl18mm_-_E3Dv6_InductionMount.STL
216 Ko · 1 184 téléchargements
-
stl50mm_-_Fanbracket.stl
2.1 Mo · 1 020 téléchargements
-
stl50mm_-_FanDuct.stl
19.9 Mo · 1 008 téléchargements
-
stlFan_Adapter.stl
74 Ko · 1 053 téléchargements
Description
I made this to have a compact design which will fit my E3D v6 and also the induction sensor On my Prusa i3 Rework. My goal was to have the sensor as close as possible to the extruder (without touching), so I can reach all the corners of the bed with ease.
Inductive sensor details:
Model: LJ12A3-4-Z/BX
Type: NPN
Voltage range DC6-36V
Output current: 300mA
Dimensions: M12x10x55mm
Detection Distance: 4 mm
Output Status: Normally Open
