Bionic Bookshelf Mount

par ThatEngineeringGuy

Fichiers imprimables (2)

  • step

    Boardholder_V004.STEP

    2.8 Mo · 1 779 téléchargements

  • stl

    Boardholder_V004.STL

    242.1 Mo · 2 398 téléchargements

Description

I was testing a new topology optimization software, and having issues with a real life part, decided to try the simplest thing I could think of: A shelf mount. This part is optimized for maximum load with minimal material use. The screenshot shows the part under a 50 kg (110 lbs) load (!), with material stress staying under 20 MPa.
In addition, the part is designed to print completely without supports. Print time around 5 hours on my Prusa i3 MK3s.
